| 参数 | 数值 |
|---|---|
| Launch Date | Q1'21 |
| Supported Operating Systems | Windows 11, 64-bit*, Windows 10, 64-bit*, Windows 10 IoT Enterprise*, Red Hat Linux*, Ubuntu 20.04 LTS* |
| Lithography | 10 nm SuperFin |
| Processor Included | Intel® Celeron® 6305 Processor (4M Cache, 1.80 GHz, with IPU) |
| Warranty Period | 3 yrs |
| Included Memory | 4GB (single-channel) |
| Memory Types | LPDDR4x-4266 |
| PCI Express Configurations ‡ | 1x PCIe x4 Gen 3 (NVMe/SATA) 1x PCIe x4 Gen 3 (NVMe) 1x PCIe x1 Gen 3 |
| Graphics Output | 2x DDI (DP or HDMI), 1x DP/typeC, 1x eDP |
| USB Configuration | 4x USB 3.2 Gen 2 3x USB 2.0 |
| Integrated Wireless‡ | Intel® Wi-Fi 6 AX201 |
| Additional Headers | HD Audio, DMIC, eSPI |
| # of Thunderbolt™ Ports | 1x Thunderbolt™ 4 |
From rugged systems in unique environments to full systems in a business or vertical environment, Intel® NUC Element product let you deliver ideal, custom solutions with minimal R&D time. With the performance and reliability you’ve come to expect from Intel, this flexible, modular computing solution is another example of how Intel-designed innovations are answering the world’s toughest business and education challenges.
Intel® NUC Compute Elements is modular computing made easy. Intel® NUC Elements give you an entirely new way to design and build integrated solutions and Mini PCs. Intel® NUC Compute Elements, along with Intel NUC Board and Chassis Elements, deliver the flexibility of modular computing so you can create the exact systems your customers want.
Whether you're building a custom system and only need compute, or a semi-custom or complete Mini PC solution, start with the Intel NUC Compute Element.
Modular Components for Custom Solutions. Choose the right small, powerful Intel® NUC Element for every deployment. The modular components of the Intel® NUC Element family give you an entirely new way to design, build, and refresh integrated systems and mini PCs. Start your deployment with a small, powerful Intel® NUC Compute Element. Then, depending on your needs, add a third-party or Intel® NUC Board and Chassis Element. That’s all it takes to crate the exact systems your clients want—with lower inventory costs and less R&D time.
Intel® NUC elements are an entirely new way to design and build embedded solutions and mini PCs. The Intel® NUC compute element along with a series of Intel-designed components, deliver the flexibility of modular computing.
How It Works
To build a customized deployment for your market, start with an Intel NUC Compute Element with the Intel® processor you need. Select SKUs also come with the Intel vPro® platform for remote manageability, hardware-enhanced security, and PC fleet stability.
Pair the Intel NUC Compute Element with an Intel® NUC Board Element qualified for 24/7 sustained operation or with your own or a third-party board. Use an Intel NUC Chassis Element to build a full mini PC solution for collaboration or rugged environments.
