125°C maximum total temperature operation
Low profile surface mount inductor
12.5mm x 12.5mm x 4.5mm shielded drum core
Ferrite core material
Inductance range from 0.47μH to 1000μH
Current range from 24.4 Amps to 0.44 Amps
Frequency range up to 1MHz
