The PAM3104 is a dual channel, low noise, and low dropout regulator sourcing up to 150mA at each channel. The range of output voltage is from 1.2V to 3.6V by operating from 2.5V to 5.5V input.
The PAM3104 offers 2% a accuracy, extremely low dropout voltage(120mV@150mA), and extremely low ground current. The shutdown current is near zero current which is suitable for battery-powerd devices. Other features include current limiting, over temperature, output short circuit protection.
The high PSRR of PAM3104 make it useful in applications where AC noise on the input power supply must be suppressed.
The PAM3104 can operate stable with very small output capacitors down to 1uF, reducing required board space and component cost.
The PAM3104 is available in SOT23-6 package.
Output Accuracy: 2%
Wide Operation Voltage Range: 2.5V to 5.5V
Dual LDO Outputs(150mA/150mA)
Low Dropout Voltage: 120mV@150mA
High PSRR: 70dB
Current Limiting
Short Circuit Protection
Thermal Shutdown
Space Saving SOT23-6 Package
RoHS Pass and Green Package
